Contact UsStair Climbing Crane TT-270 | Mini-Telescopic Crane| Stair crawlers and urban carriers
The Twin-Track TT-270 stair climbing crane is an innovative solution that combines a powerful crane with our stair climbing platform. It offers versatile lifting, making it ideal for moving heavy loads on job sites and multi-level buildings. It’s the only crane specially designed for stair climbing, thanks to its unique geometry, traction and stability. Its low height enables it to pass through the entrances to public buildings. Revolutionize your material handling with this cutting-edge equipment.
- Electric / Zero emissions
- Ultra-compact
- Remote controlled
- The only stair climber with a telescopic crane on the market designed specifically for stairs
- Can easily pass through a human door
- 2 in 1 equipment: the telescopic crane is mounted on a removable interface. It can be removed to use the TT-66 (stair climber/urban carrier) as a simple transporter.
TT-270 highlights
Width : 30 in
Load capacity 8.5 ft reach: 2200 lb
Pick and Carry Capabilities: 500 lb
Turning diameter : 70 in
Typical applications
Lifting construction materials in multi-level buildings
Installation of building mechanical systems (HVAC)
Installation and replacement of hydraulic switches in underground metro stations
What if we could help streamline your operations and boost your team’s productivity?
Comparison chart
Smart technology
Smart technology
Features
Features
Battery Powered
Wireless remote-controlled
Zero-turn capability
Built-in charger
Motion and tilt Alarm
Advanced speed control
Automatic gradient/speed monitoring
Motor brake
Upgradable and configurable software
2-in-1 equipment (removable crane)
Lifting rings
Stair-climbing capability
-
All-terrain capability
Pick & Carry capability
-
-
Characteristics
Characteristics
Length
80 3/4 in
Width
30 1/2 in
Height
88 1/2 in
Weight
2875 lbs
Ground Clearance
9 in
Turning diameter
91 in
80 3/4 in
30 1/2 in
80 3/4 in
2470 lbs
2 1/8 in
91 in
Performance
Performance
Lifting capacity (At maximum reach)
1100 lbs at 16' 5''
Lifting capacity (In front of the equipment)
2090 lbs at 8' 9''
Lifting capacity (with optional manual extension)
770 lbs at 19' 8''
Max crane rotation
11°
Max payload on platform
2200 lbs
Max pitch angle (when moving the machine)
15°
Max roll angle (when moving the machine)
10°
Max speed (leveled surface)
200 ft/min
1100 lbs at 16' 5''
2200 lbs at 8' 2''
770 lbs at 19' 8''
11°
500 lbs
35°
N/A
200 ft/min
Options & Accessories
Options & Accessories
Portable winch
Manual extension 4ft
Capstan
